我在这个问题这儿卡了2个月了,我用pointwise划分了一个复杂地型网格,计算域300030001000,最小网格长宽为30*30,第一层网格高度为50cm,我计算的时候出现如下现象,到最后一行,算例自动停止。
我最初的想法是将of自带的一个例子里的网格替换成用pointwise生成的网格,进行计算,不知道出了什么问题,希望能得到各位老师的帮助,谢谢!
/*---------------------------------------------------------------------------*\
========= |
\\ / F ield | OpenFOAM: The Open Source CFD Toolbox
\\ / O peration | Website: https://openfoam.org
\\ / A nd | Version: 6
\\/ M anipulation |
\*---------------------------------------------------------------------------*/
Build : 6-e29811f5dff8
Exec : simpleFoam
Date : Jun 07 2019
Time : 18:39:08
Host : "DESKTOP-K2TDLI2"
PID : 434
I/O : uncollated
Case : /home/dyb/turbineSiting
nProcs : 1
sigFpe : Enabling floating point exception trapping (FOAM_SIGFPE).
fileModificationChecking : Monitoring run-time modified files using timeStampMaster (fileModificationSkew 10)
allowSystemOperations : Allowing user-supplied system call operations
// * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * //
Create time
Create mesh for time = 0
SIMPLE: Convergence criteria found
p: tolerance 0.001
U: tolerance 0.0001
"(k|epsilon)": tolerance 0.0001
Reading field p
Reading field U
Reading/calculating face flux field phi
Selecting incompressible transport model Newtonian
Selecting turbulence model type RAS
Selecting RAS turbulence model kEpsilon
kEpsilonCoeffs
{
Cmu 0.09;
C1 1.44;
C2 1.92;
sigmaEps 1.11;
C3 0;
sigmak 1;
}
No MRF models present
No finite volume options present
Starting time loop
Time = 0.5
smoothSolver: Solving for Ux, Initial residual = 1, Final residual = 0.130925946068, No Iterations 1000
smoothSolver: Solving for Uy, Initial residual = 1, Final residual = 0.305787562946, No Iterations 1000
smoothSolver: Solving for Uz, Initial residual = 1, Final residual = 1.18059515052, No Iterations 1000
如下是我的一些设置
fvSolution
/*--------------------------------*- C++ -*----------------------------------*\
========= |
\\ / F ield | OpenFOAM: The Open Source CFD Toolbox
\\ / O peration | Website: https://openfoam.org
\\ / A nd | Version: 6
\\/ M anipulation |
\*---------------------------------------------------------------------------*/
FoamFile
{
version 2.0;
format ascii;
class dictionary;
object fvSolution;
}
// * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * //
solvers
{
p
{
solver GAMG;
tolerance 1e-7;
relTol 0.1;
smoother GaussSeidel;
}
U
{
solver smoothSolver;
smoother GaussSeidel;
tolerance 1e-8;
relTol 0.1;
nSweeps 1;
}
k
{
solver smoothSolver;
smoother GaussSeidel;
tolerance 1e-8;
relTol 0.1;
nSweeps 1;
}
epsilon
{
solver smoothSolver;
smoother GaussSeidel;
tolerance 1e-8;
relTol 0.1;
nSweeps 1;
}
}
SIMPLE
{
nNonOrthogonalCorrectors 0;
residualControl
{
p 1e-3;
U 1e-4;
"(k|epsilon)" 1e-4;
}
}
relaxationFactors
{
fields
{
p 0.3;
}
equations
{
U 0.7;
k 0.7;
epsilon 0.7;
}
}
cache
{
grad(U);
}
// ************************************************************************* //
fvSchemes
/*--------------------------------*- C++ -*----------------------------------*\
========= |
\\ / F ield | OpenFOAM: The Open Source CFD Toolbox
\\ / O peration | Website: https://openfoam.org
\\ / A nd | Version: 6
\\/ M anipulation |
\*---------------------------------------------------------------------------*/
FoamFile
{
version 2.0;
format ascii;
class dictionary;
object fvSchemes;
}
// * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * //
ddtSchemes
{
default steadyState;
}
gradSchemes
{
default Gauss linear;
}
divSchemes
{
default none;
div(phi,U) bounded Gauss upwind;
div(phi,epsilon) bounded Gauss upwind;
div(phi,k) bounded Gauss upwind;
div((nuEff*dev2(T(grad(U))))) Gauss linear;
}
laplacianSchemes
{
default Gauss linear limited corrected 0.33;
}
interpolationSchemes
{
default linear;
}
snGradSchemes
{
default limited corrected 0.33;
}
// ************************************************************************* //
controlDict
/*--------------------------------*- C++ -*----------------------------------*\
========= |
\\ / F ield | OpenFOAM: The Open Source CFD Toolbox
\\ / O peration | Website: https://openfoam.org
\\ / A nd | Version: 6
\\/ M anipulation |
\*---------------------------------------------------------------------------*/
FoamFile
{
version 2.0;
format ascii;
class dictionary;
object controlDict;
}
// * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * //
application simpleFoam;
startFrom latestTime;
startTime 0;
stopAt endTime;
endTime 1000;
deltaT 0.5;
writeControl timeStep;
writeInterval 50;
purgeWrite 0;
writeFormat binary;
writePrecision 12;
writeCompression off;
timeFormat general;
timePrecision 6;
runTimeModifiable yes;
libs ("libatmosphericModels.so");
// ************************************************************************* //
